2-SAFETYINFORMATION

Fanbelt

Partnumber:KHP1337

Thisdecalwarnsthatthefanandthefanbeltmustnever

betouchedwhiletheengineisrunning.Stoptheengine

beforeperforminganyoperation.

SMIL13CEX2544AB35

Batterymasterswitch

Partnumber:KHP20210

Thisswitchshutsoffthebatterywhenturnedoffposition.

Refertotheoperatormanualforthedetailedinstructions.

Theswitchisexclusivelyfortheservicepurposesuchas

weldingandelectricalrepairwork.

SMIL13CEX2545AB36

Checkvalve

Partnumber:KHP17390

Thisdecalindicatesthatifthecheckvalveoftherecoil

springisloosened,thevalvemayyout.Itindicatesthat

checkvalvelooseningmustbeperformedcorrectlyafter

readingtheoperator'smanual.

SMIL13CEX2858AB37

Batteries

Partnumber:KHP17430

Thisdecalshowsthatitisnecessarytoconsulttheoper-

ator’smanualbeforehandlingthebatteries.

SMIL13CEX2547AB38

2-26
