3-CONTROLS/INSTRUMENTS

Proportionalswitch(ifequipped)

Thisswitchisusedforoptionalaccessoriessuchashy-

draulicbreakeretc.

NOTICE:consultyourCASECONSTRUCTIONDealerto

selecttheoptionalaccessorycompatiblewithyourma-

chineandtocorrectlyadjusttheowrequiredforitsuse.

SMIL13CEX2583BA6

Lowowhydrauliccircuitcontrolswitch(if

equipped)

Thisswitchisusedforoptionalaccessoriessuchas

clamshelletc.

NOTICE:consultyourCASECONSTRUCTIONDealer

beforemountingoptionaltools.

SMIL13CEX2585BA7

3-8
