3-CONTROLS/INSTRUMENTS
1.Enginecoolanttemperaturegauge
Displaysthetemperatureoftheenginecoolant.
Thelowerzoneindicatesthattheenginecoolanttem-
peratureislow.
Whenthetemperaturegaugedisplayreachestheup-
perzone,analarmsoundsand"Overheat"isdis-
played(see"Messagescreens").
Lowertheenginespeed.
Ifthetemperaturedoesnotgodown,stoptheengine,
removetheignitionkey,andinvestigatethecause.
2.Hydraulicoiltemperaturegauge
Displaysthetemperatureofthehydraulicoil.
Thelowerzoneindicatesthatthehydraulicoiltem-
peratureislow.
Whenthetemperaturegaugedisplayreachestheup-
perzone,analarmsoundsand"Overheat"isdis-
played(see"Messagescreens").
Lowertheenginespeed.
Ifthetemperaturedoesnotgodown,stoptheengine,
removetheignitionkey,andinvestigatethecause.
3.Fuelgauge
Displaystheremainingamountoffuelbythenumber
oflitsegments.
Whenallarelit,itindicatesthatthefueltankisfull.
Whenonly1islit,analarmsoundsand"Lowfuel"is
displayed(see"Messagescreens").
NOTE:Itisnotnecessarytowaituntilthefueltank
isemptybeforellingwithfuel.Ifthetankbecomes
empty,airbleedingofthefuelsystemisrequired.
4.Workmodeicon
Theseindicatorsdisplaytheinitialworkmodeandthe
enginespeedthatwasselectedwiththeengineac-
celerationbuttonandworkmodeselector.(Referto
pageConsoleRight-handconsole-Controliden-
tication).
5.Travelmodeicon
Atlowspeed,isdisplayed.
Athighspeed,isdisplayed.
6.Workinglight
Displayedwhenthelightison.
7.Engineautoidlingandstopselectiondisplay
Displayedwhenautoidlingisselected.
“Auton/min”.
Displayedwhenautostopisselected.
“Autoidlestop”.
Displayedwhenautoidlingand
autostopareselected.“Auto
n/min”and“Autoidlestop”.
8.Anti-theftprotection
Displayedwhentheanti-theftprotection
functionisoperating.
9.Displaystheselectedattachment
Hydraulicbreaker
Crushergrapple
10.Clockdisplay(Refertopage3-25
11.Ecogauge
Thenumberofindicatorsonthisgaugeincreases
whentheoperatingstateisenergy-savingoperation.
Ifhigh-loadoperationsareperformed,thenumberof
gaugeindicatorsdecreases.
Thestateofenergy-savingoperationsisindicated.
•Nomechanicalabnormalitieswilloccurevenifthe
numberofgaugeindicatorsdecreases.However,to
helpconservetheenvironment,trytoperformen-
ergy-savingoperationswithinthegreenrange,so
longasdoingsodoesnothinderwork.
Keypointsforenergy-savingoperations
•TrytouseHmodeorAmodeinsteadofSPmode.
•Avoidsharpleveroperations.
•Avoidhighloadandreliefoperations.
•Useautoidleandone-touchidle.
Also,useidlestoptostopunnecessaryidling.
AskyourCASECONSTRUCTIONDealerabouthow
toturntheecogaugedisplay“On”and“Off”.
12.Muteicon
Displayedwhentheradiovolumeis
muted.
13.Hourmeter
3-15
