Thehourmeterdisplaystheengineoperationtimein
unitsof0.1h(6min)
14.Fueleconomydisplay.Thetime/fuelconsumptionat
thattime“L/hr”isdisplayed.
15.Messagescreens
SMIL13CEX2599AB3
Thissectionofthedisplayscreenshowsinformation
iconsandmessagesthatchangeaccordingtotheset
applicationofthemachine.
Analarmalsosoundswhensomeofthesemessages
aredisplayed.
Thefollowingsectiondescribestheicons,mes-
sages,andtheircorrespondingexplanations.
NOTICE:Ifamessageisdisplayed,performmainte-
nanceaccordingtothemessage.
NOTICE:Ifthemessageisstilldisplayedafter
maintenance,consultyourCASECONSTRUCTION
Dealer.
NOTE:Thelanguageofthedisplayedmessagescan
bechanged,consultyourCASECONSTRUCTION
Dealer.
•
Lowoilpressure
Indicatesthattheengineoillevelislow.
Analarmsounds.Stoptheengineandre-
movetheignitionkey,andtheninspectthe
oillevel.
NOTE:Ifthemeasuresabovearenotperformedim-
mediatelywhenthismessageisdisplayed,theengine
stopsautomatically.
•
Overheat
Indicatesthattheenginecoolanttempera-
tureishigh.Analarmsounds.Lowerthe
enginespeed.Ifthetemperaturedoesnot
godown,stoptheengineandremovethe
ignitionkey.Waitforthetemperatureofthe
coolingsystemtogodown,andthenin-
spectthecoolantlevelinsidethereservoir
tankandradiator.Checktheradiatorandoil
cooler.(Refertopage6-49).
•
Boosttemphigh
Indicatesthatthetemperatureofthetur-
bochargerairthatisbeingsuppliedto
theengineisabnormallyhigh.Analarm
sounds.Theengineautomaticallyenters
idlingmodeasapreventativemeasure.
Stopthemachine,operatetheengineat
idlingspeed,andwaituntilthemessage
disappears.Iftheturbochargerairtempera-
tureonthedisplayscreencontinuestorise,
theenginestopsautomatically.Consult
yourCASECONSTRUCTIONDealer.
•
Alternator
Indicatesthatthereisaproblemintheal-
ternator.Analarmsounds.Stoptheen-
gineandremovetheignitionkey,andthen
inspectthealternator.ConsultyourCASE
CONSTRUCTIONDealer.
•
Checkengine
Indicatesthatthereisaproblem(shortor
disconnection)intheelectricalsystemofthe
engine.Analarmsounds.Stoptheengine
andremovetheignitionkey,andthenin-
specttheelectricalsystem.Consultyour
CASECONSTRUCTIONDealer.
•
Elec.problem
Indicatesthatthereisaproblemintheelec-
tricalsystem.Analarmsounds.Inthiscase,
stoptheengineandremovetheignitionkey,
andtheninvestigatethecauseorconsult
yourCASECONSTRUCTIONDealer.
•
Enginestop
Indicatesthattheemergencystopswitch
operated.Analarmsounds.Toenablethe
enginetobestartedagain,theswitchmust
becanceled.
•
Impropershutdown
Performlowidlingforatleast5minbefore
stoppingtheengine.
•
Checkcamera
Indicatesthatthereisaproblem(shortor
disconnection)inthemonitorcameracon-
nection.
•
Overload
Theloadisexcessive.Reducetheload.
•
Lowcoolant
