34 SECTION 21 - TRANSMISSION
Remove the screw, the washer, the O-ring and ex-
tract the 4WD yoke and the spacer (on 4WD models
only).
Remove 17 screws and using a suitable hoist take
off the rear transmission case.
Lever slots are provided to assist removal.
NOTE: the bearing cones and shims may fall from
the rear case during removal.
IMPORTANT: for proper reassembly, take note and
mark which bearings and shims come from which lo-
cations.
Remove the 4WD shaft assembly (on 4WD models
only).
Tilt the countershaft and withdraw the input shaft as-
sembly.
