8 SECTION 27 - REAR AXLE
1.3 DISASSEMBLY AND ASSEMBLY
REAR AXLE REMOVAL
For servicing of any rear axle component the axle
must be removed.
Prior to removal of the axle place a suitable clean
container under the axle, capable of holding 21.2 li-
tres and drain the oil from the plug at the base of the
axle.
Disconnect the differential lock lever.
Gain access from the top of the rear axle, disconnect
and drain the residual brake oil into a suitable clean
container. Remove the pipes from both sides of the
axle half shafts. Plug the brake pipes to prevent any
dirt or contamination entering the brake system.
Remove the 4 attaching screws from the drive shaft
coupling and remove from the axle.
Before removal of the axle make sure the machine is
on level ground with the loader fully lowered and
backhoe resting on the ground. The stabilizers must
be lowered to the ground and the front wheels
chocked.
Support the axle and remove the retaining screws,
gently lower the axle to the ground.
Place the axle on a suitable stand to facilitate the re-
pairs.
