SECTION 50 - CAB HEATING AND AIR CONDITIONING 3
1. SPECIFICATIONS
HEATING
ENGINE RADIATOR COOLANT
Antifreeze - Ambra Agriflu 12 litres
Water 12 litres
System type Pressurized FULL FLOW by-pass with
expansion chamber
FAN BELT DEFLECTION
Naturally aspired 13 - 19 mm
Turbocharged 10 - 16 mm
THERMOSTAT
Start to open at 82 °C
Fully open at 95 °C
Radiator cap 0.90 bar
TORQUE VALUES
Coolant/hot water hose connections 5 Nm
Air hose ducting connections 5 Nm
Heater housing to floor mounting bolts 6.2 Nm
Refrigerant HFC 134a
Refrigerant charge 1.2 kg
Compressor oil SP20 (PAG Type, Viscosity index 100)
Oil change amount 135 cc
CHECK CONDITIONS
Air inlet temperature 37.8 °C
Rated air inlet moisture 40%
Evaporation temperature 0 °C
Overheating 5 °C
Inlet air speed 1.0 - 2.0 - 3.0 m/s
Condensation temperature 58 °C (absolute 16 bar)
Undercooling 2 °C
