Case 580SR+ - Transmission

8 SECTION 02 - TECHNICAL SPECIFICATIONS
3.2 TRANSMISSION
2WD/2WS TRANSMISSION - POWERSHUTTLE (580SR)
Model ...............................................................................................................................Turner COM-T4-2025
Type (4x4) ................................................................................................ 4 forward and 4 reverse travel gears
Torque converter ratio ................................................................................................................................. 2.38
Transmission ratios:
1st forward travel.....................................................................gear 4.824:1 reverse travel gear 4.020:1
2nd forward travel ...................................................................gear 2.998:1 reverse travel gear 2.496:1
3rd forward travel ....................................................................gear 1.408:1 reverse travel gear 1.173:1
4th forward travel ....................................................................gear 0.792:1 reverse travel gear 0.660:1
4WD/2WS TRANSMISSION - POWERSHUTTLE (580SR+ / 590SR)
Model ...............................................................................................................................Turner COM-T4-2025
Type (4x4) ................................................................................................ 4 forward and 4 reverse travel gears
Torque converter ratio ................................................................................................................................. 2.38
Transmission ratios:
1st forward travel.....................................................................gear 4.824:1 reverse travel gear 4.020:1
2nd forward travel ...................................................................gear 2.998:1 reverse travel gear 2.496:1
3rd forward travel ....................................................................gear 1.408:1 reverse travel gear 1.173:1
4th forward travel ....................................................................gear 0.792:1 reverse travel gear 0.660:1
4WD/2WS TRANSMISSION - POWERSHIFT (580SR+ / 590SR)
Model ........................................................................................................................................... Dana T16000
Type (4x4) ................................................................................................ 4 forward and 2 reverse travel gears
Torque converter ratio ............................................................................................................................... 2.261
Transmission ratios:
(upper output)
1st forward travel.....................................................................gear 4.863:1 reverse travel gear 4.085:1
2nd forward travel ...................................................................gear 2.571:1 reverse travel gear 2.160:1
3rd forward travel ....................................................................gear 1.284:1
4th forward travel ....................................................................gear 0.679:1
(lower output)
1st forward travel.....................................................................gear 4.625:1 reverse travel gear 3.885:1
2nd forward travel ...................................................................gear 2.446:1 reverse travel gear 2.055:1
3rd forward travel ....................................................................gear 1.221:1
4th forward travel ....................................................................gear 0.646:1
4WD/4WS TRANSMISSION - POWERSHIFT (695SR)
Model ........................................................................................................................................... Dana T16000
Type (4x4) ................................................................................................ 4 forward and 2 reverse travel gears
Torque converter ratio ............................................................................................................................... 2.261
Transmission ratios:
(upper output)
1st forward travel.....................................................................gear 4.863:1 reverse travel gear 4.085:1
2nd forward travel ...................................................................gear 2.571:1 reverse travel gear 2.160:1
3rd forward travel ....................................................................gear 1.284:1
4th forward travel ....................................................................gear 0.679:1
(lower output)
1st forward travel.....................................................................gear 4.625:1 reverse travel gear 3.885:1
2nd forward travel ...................................................................gear 2.446:1 reverse travel gear 2.055:1
3rd forward travel ....................................................................gear 1.221:1
4th forward travel ....................................................................gear 0.646:1
