Case 580SR+ - Axles; Brakes

SECTION 02 - TECHNICAL SPECIFICATIONS 9
3.3 AXLES
FRONT AXLES
Front 2WD/2WS axle (580SR)
Model ..................................................................................................................................... CARRARO 26.00
Type .......................................................................................................................................................steering
Front 4WD/2WS axle (580SR / 590SR)
Model ..................................................................................................................................... CARRARO 26.16
Type .......................................................................................................................................................steering
Front 4WD/4WS axle (695SR)
Model ..................................................................................................................................... CARRARO 26.28
Type .......................................................................................................................................................steering
REAR AXLES
Rear 2WS axle (580SR / 590SR)
Model .................................................................................................................................................. CNH D46
Type .............................................................................................................................................................rigid
Differential lock (powershuttle axle) ................................................................................................. mechanical
Differential lock (powershift axle) ......................................................................................................... electrical
Rear 4WS axle (695SR)
Model .................................................................................................................................. CARRARO 26.32M
Type .......................................................................................................................................................steering
Differential lock .................................................................................................................................... electrical
3.4 BRAKES
BRAKES - 2WS
Service brake
Type .......................................................................................................wet multi-discs, 8 x axle (4 x half axle)
Braking surface ................................................................................................................................... 1440 cm
2
Parking brake
Type ........................................................................................................................ single disc on transmission
BRAKES - 4WS
Service brake
Type .......................................................................................................wet multi-discs, 6 x axle (3 x half axle)
Braking surface ................................................................................................................................... 1440 cm
2
Parking brake
Type ........................................................................................................................ single disc on transmission
