SECTION 33 - BRAKES SYSTEM 3
1. SPECIFICATIONS
2WS
4WS
The loader backhoe has two braking systems:
a parking brake with two free floating friction pads;
hydraulically operated inboard wet disc brakes in the
rear axle.
The parking brake, when engaged, locks the brake
disc on the rear of the transmission.
Operation of the foot brake, instead, pressurizes the
brake fluid in the master cylinders which feeds the
brake pistons in the axle housing. The brake pistons
then compress the brake friction discs and separa-
tion discs, which locks the axle shaft to the axle
housing.
BRAKES OPERATION HYDRAULIC
Brakes Wet disc, piston operated
Oil brake Akcela LHM
Number discs (on side) 4
Brakes disc total friction area
1,440 cm
2
BRAKES OPERATION HYDRAULIC
Brakes Wet disc, piston operated
Oil brake Akcela LHM
Number discs (on side) 3
Brakes disc total friction area
1,440 cm
2
