16 SECTION 41 - STEERING SYSTEM
3.3 DISASSEMBLY AND ASSEMBLY
DISASSEMBLY
To gain access to the power steering, remove the
hood and the air filter.
Removing power steering
Disconnect the four connectors and collect the O-
ring seals, noting the connector positions.
Remove the four screws from within the cab.
The power steering can be removed from the front of
the cab through the engine compartment. Place the
steering unit in the holding tool.
Screw off the screws (18), the special screw (17)
and the washers (16) from the end cover (15).
