SECTION 50 - CAB HEATING AND AIR CONDITIONING 17
3.3 CONTROLS AND OPERATION
CONTROLS (580SR)
The air conditioning control can be adjusted to obtain
the desired temperature in the cab.
To activate air conditioning, turn the selector (2).
Upon activation, the warning lamp (3) turns on. The
selector (1) allows choosing the ideal temperature
according to your requirements. Positioning selector
(1) to “0” and turning selector (2) you will obtain more
or less cold according to the selector (2) position. By
positioning selector (1) to any other position different
from “0”, you will obtain instead a mixture of warm
and cold air and the desired climate inside the cab.
NOTE: the air conditioning can be operated only if
the ventilation selector (4) is not set to the stop posi-
tion.
Turn the selector (4) for air capacity according to
your requirements.
CONTROLS (580SR+ / 590SR / 695SR)
The air conditioning control can be adjusted to obtain
the desired temperature in the cab.
To activate air conditioning, turn the selector (2).
Upon activation, the warning lamp (4) on the side in-
strument cluster turns on. The selector (1) allows
choosing the ideal temperature according to your re-
quirements. Positioning selector (1) to “0” and turn-
ing selector (2) you will obtain more or less cold
according to the selector (2) position. By positioning
selector (1) to any other position different from “0”,
you will obtain instead a mixture of warm and cold air
and the desired climate inside the cab.
NOTE: the air conditioning can be operated only if
the ventilation selector (3) is not set to the stop posi-
tion.
Turn the selector (3) for air capacity according to
your requirements.
1
2
3
