SECTION 41 - STEERING SYSTEM 13
3.1 SPECIFICATIONS
MOUNTING SCREW TORQUE
Displacement (2WS) 125 cc/rev
Displacement (4WS) 160 cc/rev
Shock valve adjustment (2WS) 200 ÷ 220 bar
Shock valve adjustment (4WS) 240 ÷ 260 bar
3/4 - 16 UNF Nm 60
7/16 - 20 UNF Nm 20
Steering wheel nut Nm 55
Steering motor to steering column bracket Nm 23
Power steering end cover Nm 30
Power steering pipe connection Nm 45
Steering motor pipe adaptors Nm 55
Check valve bolt Nm 30
Shock valve (4WS) Nm 30
