26 SECTION 02 - TECHNICAL SPECIFICATIONS
5. BACKHOE ATTACHMENT LIFTING CAPACITY
580SR / 580SR+ / 590SR
Lifting capacity in normal operating mode - SAE
rated
The following table reports the lifting capacities of the
dipper (A) and the boom (B).
NOTE: the capacities indicated may slightly vary
from one machine to another, according to the ac-
cessories mounted, the pressure settings and the
market requirements.
Lifting capacities are given in kg for a standard dip-
per and a telescopic dipper.
Standard dipper
Telescopic dipper
(retracted)
Telescopic dipper
(extended)
Height/Depth
Dipper - A Boom - B Dipper - A Boom - B Dipper - A Boom - B m
610 +5.4
1200 1120 920 +4.9
1590 1490 1515 1040 +4.3
2040 1690 1930 1580 1490 1100 +3.6
1975 1710 1870 1590 1470 1125 +3.0
2010 1650 1900 1540 1490 1135 +2.4
2165 1560 2050 1440 1555 1135 +1.8
2630 1510 2495 1390 1685 1105 +1.2
3860 1490 3690 1370 1950 1090 +0.6
1500 1375 2785 1090 0 (ground)
1540 1405 3850 1100 -0.6
1530 1380 1110 -1.2
1520 1370 1115 -1.8
1540 1380 1125 -2.4
1605 1435 1155 -3.0
1875 1675 1210 -3.6
1360 -4.2
1930 -4.8
