SECTION 02 - TECHNICAL SPECIFICATIONS 25
TYRES FRONT REAR
440/80R28 440/80R28
Dimensions standard dipper telescopic dipper (extended)
A 1870 mm 2855 mm
B 200° 200°
C 5737 mm 6421 mm
D 4002 mm 4686 mm
E 5836 mm 6922 mm
F 7161 mm 8247 mm
G 6346 mm 7432 mm
J 4556 mm 5738 mm
K 2280 mm 2280 mm
L 2790 mm 2790 mm
M 14° 14°
Performance standard dipper telescopic dipper (extended)
Swing arc 180° 180°
Maximum digging force - dipper
cylinder
3744 daN 2643 daN
Maximum digging force - bucket
cylinder
5603 daN 5603 daN
Lift capacity through dipper arc 2350 kg 1560 kg
Lift capacity, dipper 3.66 m above
ground
2475 kg 1560 kg
Lift capacity at 4.26 m above
ground
1470 kg 950 kg
Telescopic dipper extension
length
- 1200 mm
BACKHOE BUCKETS
Struck capacity SAE J 296 Width Weight
76 l 305 mm 108 kg
109 l 457 mm 130 kg
153 l 610 mm 160 kg
196 l 762 mm 180 kg
238 l 914 mm 208 kg
