SECTION 50 - CAB HEATING AND AIR CONDITIONING 53
3.9 COMPRESSOR
SPECIFICATIONS
Basic compressor specifications
Displacement ............................................................................................................................................155 cc
Weight........................................................................................................................................................9.9 kg
Oil type........................................................................................................................................................SP20
Rotation.............................................................................................................................. CW (Clockwise only)
Air gap, clutch, compressor and pulley ............................................................................................. 0.9-0.8 mm
Belt tension
Measure at the widest gap.................... 10 mm deflection with 1 kg force applied midway between the pulleys
Speed rating
Tightening torques
MAXIMUM RPM
Constant Downshift
6000 8000
COMPONENT Nm
Armature retaining nut, M8 17.7±2.9
Cylinder head bolts, M6 13.7±2.9
Cylinder head bolts, M8 34.3±4.9
Clutch dust cover screw, M5 9±2
Oil filler plug 19.6±4.9
