10 SECTION 84 - BACKHOE
CROSS-PATTERN CONFIGURATION
Backhoe boom and backhoe attachment swing
left-hand control lever
This lever has five positions:
Position (0): neutral/hold. This position enables the
attachment movement to be stopped. As soon as the
lever is released, it automatically returns to the neu-
tral position (0) and the attachment remains in the
position where it was when movement stopped.
Position (A): the boom lowers.
Position (B): the boom rises.
Position (C): the backhoe attachment swings to the
left.
Position (D): the backhoe attachment swings to the
right.
Backhoe dipper and backhoe bucket right-hand
control lever
This lever has five positions:
Position (0): neutral/hold. This position enables the
attachment movement to be stopped. As soon as the
lever is released, it automatically returns to the neu-
tral position (0) and the attachment remains in the
position where it was when movement stopped.
Position (E): the backhoe dipper extends.
Position (F): the backhoe dipper retracts.
Position (G): the backhoe bucket closes.
Position (H): the backhoe bucket opens.
