216
SECTION 21 - TRANSMISSION
SECOND CLUT
CH DRUM DISASSEM
BL
Y
Press the upper output gear from the secon
d shaft.
Press the gear from second shaft.
Remove the gear retaining ring.
Remove the clutch
shaft seali
ng rings.
www
.maskinisten.net
Copyright ©
281
