SECTION 21 - TRANSMISSION 251
Install the upper and the lower output at the same
time.
Do not force this operation, be sure discs of discon-
nect are in full position. Using caution as not to dam-
age any of the lower shaft sealing rings.
Install the baffle plate, the mounting screws, the
washers and the nuts. Tighten the nuts to the spec-
ified torque. (Use Loctite 243).
Install the baffle plate, the mounting screws, the
washers and the nuts. Tighten the nuts to the spec-
ified torque. (Use Loctite 243).
Install the oil baffle, the mounting screws and the
washers. Tighten the screws to the specified torque.
(Use Loctite 243).
