56 SECTION 25 - FRONT AXLES
DIFFERENTIAL SUPPORT
Disassembly
Drain the oil completely from the differential.
Loosen and remove the screws (2) of the differential
support (1).
Remove the differential support (1) from the axle
housing (14).
SWARNING
Support the differential support with a rope or other
appropriate means.
F27282
4
5
3
1
2
7
89
6
13
14
12
11
10
9
8
1
2
14
F27283
