SECTION 25 - FRONT AXLES 67
PINION GROUP
Disassembly
Position the differential carrier in a vise.
Unscrew the ring nut (10) using the special tool
380002218.
NOTE: this operation will irretrievably damage the
ring nut (10).
10
F27320
