Case 580SR+ - Page 433

SECTION 25 - FRONT AXLES 81
LUBRICATION AND GREASING
Oil capacity 11.0 litres
Oil specification:
use recommended oil enriched in additives
Note: do not use synthetic or vegetable oil without consent of the axle
manufacturer
Akcela Nexplore MAT3525
DESCRIPTION POSITION
Oil level plug 1
Air breather 2
Level, fill and drain plug for reduction gear oil 3
Oil drain plug 4
Greasing points 5
F27379
3 5
5
55
52
5 3
1 4
