Case 580SR+ - Page 437

SECTION 25 - FRONT AXLES 85
Remove the seal ring (13).
Unscrew the screws (11) and remove the flange
(12).
Loosen the bolt (4).
Take the rear support (5) out from the differential
support.
Remove the O-ring (7) from the rear support (5).
NOTE: this is a destructive operation for the O-ring
(7).
F27382
13
F27383
12
11
F27384
4
5
F27385
5
7
