Case 580SR+ - Page 45

SECTION 02 - TECHNICAL SPECIFICATIONS 23
TYRES FRONT REAR
440/80R28 440/80R28
Dimensions standard dipper telescopic dipper (extended)
A 1899 mm 2844 mm
B 200° 200°
C 5815 mm 6492 mm
D 3908 mm 4615 mm
E 5903 mm 6990 mm
F 7228 mm 8315 mm
G 6518 mm 7605 mm
J 4623 mm 5805 mm
K 2280 mm 2280 mm
L 2790 mm 2790 mm
M 14° 14°
Performance standard dipper telescopic dipper (extended)
Swing arc 180° 180°
Maximum digging force - dipper
cylinder
3623 daN 2591 daN
Maximum digging force - bucket
cylinder
5234 daN 5234 daN
Lift capacity through dipper arc 2260 kg 1610 kg
Lift capacity, dipper 3.66 m above
ground
2325 kg 1610 kg
Lift capacity at 4.26 m above
ground
1520 kg 1000 kg
Telescopic dipper extension
length
- 1200 mm
BACKHOE BUCKETS
Struck capacity SAE J 296 Width Weight
76 l 305 mm 108 kg
109 l 457 mm 130 kg
153 l 610 mm 160 kg
196 l 762 mm 180 kg
238 l 914 mm 208 kg
