Case 580SR+ - Page 549

SECTION 27 - REAR AXLE 57
DIFFERENTIAL GROUP (STANDARD)
Disassembly
Loosen the screw (4) and remove the ring nut retain-
er (5).
Unscrew the ring nut with suitable special tool
320002218.
Remove the ring nut (6).
F28050
8
7
6
14
15
12
11
4
2
3
14
15
5
4
1
5
18
9
6
10
17
16
13
F28051
4
6
5
