66 SECTION 27 - REAR AXLE
Loosen all screws (1) of the ring gear (10).
SWARNING
This operation makes both differential half boxes
free, so take care not to lower the inner compo-
nents.
Remove the ring gear (10) by means of a hammer.
Check the marking points (8) and (9) that will be
useful during the assemblage.
Assemble the discs (11) and (12).
F28056
1
10
10
F28057
F28058
8
9
11 12
F28074
