SECTION 27 - REAR AXLE 69
Position the shaft (17), the gears (16) and the spher-
ical washers (15).
Assemble the gear (19) and the shim (13).
Assemble discs (11) and (12).
Assemble the two half housings of the differential
unit (8) and (9).
SWARNING
Carefully check that the marks of both differential
half housings coincide.
15
16
15
16
17
F28082
19
13
F28081
11 12
F28074
F28058
8
9
