SECTION 35 - HYDRAULIC SYSTEM 65
Pump pressure oil
1st stage restricted return oil
2nd stage restricted return oil
Return to oil tank
1. Control valve swing section
2. One way restrictor
3. Cushioning rod
4. Right hand cylinder
5. Left hand cylinder
6. Cushioning rod
7. One way restrictor
7
2
1
4
3
6
5
F29480
