Case 580SR+ - Page 686

96 SECTION 35 - HYDRAULIC SYSTEM
With engine stopped, release any residual pressure
by moving the control levers of stabilizers.
Disconnect all hydraulic hoses. Remove the snap
ring (4) and the shim (5). Hammer to slide out the pin
(6).
Remove the stabilizer cylinder.
