SECTION 50 - CAB HEATING AND AIR CONDITIONING 7
Schematic - Heater system
1. Heater valve mounted to the right of the heater
housing
2. Air ducting to the front windscreen
3. Radiator hoses of the heater control panel
4. Air ducting to the rear windscreen below the cab
floor
5. Air intake to the heater housing from below the
cab floor
6. Heater pipes to and from heater taken from the
engine oil
F30058
1
3
4
5
6
2
