SECTION 50 - CAB HEATING AND AIR CONDITIONING 59
Remove the snap ring (7), remove the shaft key and
lift the pulley assembly from the compressor.
Inspect the rotor assembly (8) for wear and replace
the assembly as necessary.
Remove the field coil wire retaining clip.
Remove the snap ring (9) of the coil.
F28732
7
F28733
8
F28734
F28735
9
