6 SECTION 55 - ELECTRICAL SYSTEM
COMPONENTS AND CONNECTORS
NAME DESCRIPTION
BZ1 Alarm buzzer
EV1 Double delivery solenoid valve (optional)
EV2 Hand hammer control valve (optional)
EV3 Rear hammer solenoid valve (optional)
EV4 Backhoe attachment travel solenoid
valve
EV5 Backhoe attachment lock solenoid valve
(optional)
EV6 Bucket level solenoid valve
EV7 Fuel shut off solenoid valve
EV8 4WD solenoid valve (optional)
EV9 Reverse travel solenoid valve
EV24 Lifting solenoid valve
EV25 Lifting solenoid valve
FG1 General fuse 80A
FG2 A/C fuse (not connected)
H1 Backhoe attachment lock warning light
(optional)
H2 Front left light
H3 Front right light
H4 Rear left light
H5 Number plate light
H6 Rear right light
H11 Outer front left work light
H12 Outer front right work light
H13 Outer rear left work light
H14 Outer rear right work light
H15 Rotating beacon
H16 Rotating beacon
H19 Inner front left work light (optional)
H20 Inner front right work light (optional)
H21 Inner rear left work light (optional)
H22 Front right work light (optional)
HA1 Reverse buzzer
HA2 Horn
HA3 Optional buzzer
K01 Starting relay
K02 A/C relay
K13 Antitheft unit
KC Fuse and relay control unit
M1 Starter motor
M10 Air conditioning compressor (not
connected)
R2 Engine water temperature sender
R3 Fuel level gauge
R4 Transmission temperature sender
S2 4WD switch (optional)
S3 Hand hammer switch (optional)
S4 Double delivery switch (optional)
S5 Ride control switch (optional)
S7 Backhoe attachment travel lock switch
S8 Backhoe attachment lock switch
(optional)
S9 Lights switch
S11 Front work light switch
S12 Rear work light switch
S15 Beacon lamp switch
S17 Start switch
S18 Parking brake switch
S20 Engine oil low pressure switch
S21 Air filter blocked switch
S24 Trasmission oil pressure switch
S26 Clutch disconnect button
S27 Clutch disconnect button
S28 Bucket sensor
S30 Rear hammer pedal (optional)
S31 Brake oil level sender
S32 Stop light switch
S33 Stop light switch
S40 Gearshift lever
S41 Light / windshield wiper control lever
S42 Warning switch
S44 Pneumo-electric seat (optional)
S47 Battery master switch
S48 Cold start temperature switch
S49 Air conditioning pressure switch (not
connected)
S52 Solenoid valves lock switch (optional)
S54 Rear horn button (optional)
ST2 Side instrument cluster
