22 SECTION 55 - ELECTRICAL SYSTEM
S32 Stop light switch
S33 Stop light switch
S34 Left cab light switch
S35 Right cab light switch
S40 Gearshift lever
S41 Light / windshield wiper control lever
S43 Radio (optional)
S44 Pneumo-electric seat (optional)
S45 Blower and air conditioner switch
S46 Current intake
S47 Battery master switch
S48 “Grid heater” temperature switch
S49 A/C pressure switch
S52 Solenoid valves lock switch (optional)
S53 Rear windshield washer + wiper button
S54 Rear horn button (optional)
ST2 Side instrument cluster
ST3 4x1 bucket control lever
X1
General line - engine line - 18-way
connector
X2 “Grid heater” - 6-way connector
X3 Engine stop - 1-way connector
X4 Air filter - 2-way connector
X6 Forward gear - 2-way connector
X7 Reverse travel - 2-way connector
X8 General line - rear lights - 12-way connector
X10
Solenoid valve line - general line - 29-way
connector
X12
General line - upper cab line - 5-way
connector
X13
General line - front instrument cluster - 17-
way connector
X14 Anti-theft device - 11-way connector
X15 Start switch - 10-way connector
X16 Optional - 1 way connector
X17 Pneumo-electric seat - 4-way connector
X21 Horn/left light - 7-way connector
X22 Right light - 5-way connector
X23 Clutch disconnect button - 2-way connector
NAME DESC RIPTION
X24
Backhoe attachment travel lock solenoid
valve - 2-way connector
X25
Backhoe attachment lock solenoid valve -
2-way connector
X26 Bucket sensor - 3-way connector
X27
Pilot control audible alarm button - 2-way
connector
X28 Clutch disconnect button - 2-way connector
X29 Bucket level - 2-way connector
X30
Delivery doubling solenoid valve - 2-way
connector
X31
Quick coupler solenoid valve - 2-way
connector
X32
Rear hammer solenoid valve - 2-way
connector
X34
“Glide ride” control solenoid valve - 2-way
connector
X35
Hand hammer solenoid valve - 2-way
connector
X36 Rear hammer button - 2-way connector
X37
Rear right light arrangement - 4-way
connector
X38 Rear right work light - 4-way connector
X39 Rear windshield wiper - 4-way connector
X40
Rear right work light (optional) - 4-way
connector
X41 Blower motor (optional) - 2-way connector
X42
Front right direction indicator arrangement -
4-way connector
X43 Beacon lamp - 4-way connector
X44 Front right work light - 4-way connector
X45
Front right work light (optional) - 4-way
connector
X46
Rear left work light (optional) - 4-way
connector
X47 Rear left work light - 4-way connector
X48
Rear left light arrangement - 4-way
connector
X49 Front windshield wiper - 6-way connector
X50
Front left work light (optional) - 4-way
connector
X51 Front left work light - 4-way connector
NAME DESCRIPTION
