SECTION 55 - ELECTRICAL SYSTEM 53
NAME DESCRIPTION
K1 Safety relay
S1 Pilot ON/OFF switch - 8-way connector
S2 Gearshift configuration switch - 8-way
connector
X1 Valve configuration “1” - 2-way connector
X2 Valve configuration “2” - 2-way connector
X4 Left hydraulic control lever - 2-way
connector
X11 Left stabilizer pressure switch - 2-way
connector
X12 Right stabilizer pressure switch - 2-way
connector
X13 Right towing line - 5-way connector
X14 Right hydraulic control lever - 6-way
connector
X17 Manifold power - 2-way connector
X20 Control unit - 23-way connector
X23 Safety switch - 2-way connector
X24 Left stabilizer control lever - 6-way
connector
X27 Horn jumper connection - 2-way connector
X72 Pilot control cable - 1-way connector
XL Left stabilizer control lever - 3-way
connector
XR Right stabilizer control lever - 3-way
connector
YP3 Left bottom plug 3 - 2-way connector
YP4 Left top plug 4 - 2-way connector
YP5 Right bottom plug 5 - 2-way connector
YP6 Right top plug 6 - 2-way connector
YP7 Extension plug 7 - 2-way connector
YP8 Retraction plug 8 - 2-way connector
YP9 Reverse travel auxiliary speed plug 9 - 2-
way connector
YP10 Auxiliary forward travel plug 10 - 2-way
connector
