SECTION 55 - ELECTRICAL SYSTEM 55
COMPONENTS AND CONNECTORS
NAME DESCRIPTION
A1 Right speaker (optional)
A2 Left speaker (optional)
A53 Radio (optional)
A106 Engine control unit
B107 Water in fuel sensor
B4 Air filter pressure switch
B5 Fuel level sender
B24 Accelerator knob
B25 Foot accelerator
B26 Loader bucket sensor
B30 Parking brake
B33 Speed sensor (optional)
B66 Oil temperature switch
B69 A/C pressure switch
B74 Transmission oil pressure switch
B129 Brake oil level sensor
E15 Rotating beacon
E16 Rotating beacon
E17 Warning lamp for intake
E18 Cab light
E26 Control lock warning lamp
E27 Number plate light
E28 Rear left light
E29 Rear right light
E38 Rear left work light
E40 Rear left light (optional)
E44 Front right work light
E45 Front right work light (optional)
E46 Rear left work light (optional)
E47 Rear left work light
E50 Front left work light (optional)
E51 Front left work light
E121 Front left light/audible alarm
E133 Front right light
F1 Main fuse
F2 Control unit fuse
F4 Third speed blower fuse
F5 Water in fuel fuse
F31
Fuse for anti-theft device, diagnostic
socket, menu scroll switch, display enter
switch, side instrument cluster
FG4 Fuse A/C
G1 Battery
G67 Alternator
H7 Reverse buzzer
H32 Audible alarm
HA2 Horn
K102 Relay for start signal from the control unit
K103 Start relay
K104 Starter motor relay
K105 A/C relay
M1 Starter motor
M39 Rear windshield wiper motor
M41 Blower motor (optional)
M49 Front pump
M56 Front windshield wiper motor
M57 Rear windshield wiper motor
M64 A/C compressor
S2 4WD switch
S3 Hand hammer switch
S4 Hydraulic speed control switch
S5 Drive switch
S6 Attachment switch
S8 Backhoe attachment travel lock switch
S9 Lights switch
S15 Start switch
S23 Transmission disconnect button
S28 Transmission disconnect button
S34 Left door switch
S35 Right door switch
S36 Rear hammer button (optional)
S42 Warning switch
S130 Windshield wiper/washer switch
S132 Gear switch
S136 Menu scroll switch
S137 Rear work light switch
S138 Rear pump switch
S139 Display enter switch
S140 Backhoe attachment travel lock switch
S141 Front work light switch
S144 Beacon lamp switch
NAME DESCRIPTION
