SECTION 55 - ELECTRICAL SYSTEM 57
X58 Left direction indicator - 4-way connector
X64 Air conditioning switch - 1-way connector
X67 Alternator - 3-way connector
X69 Air conditioning pressure switch - 2-way
connector
X72 3-way connector
X80 2-way connector
X81 2-way connector
X82 10-way connector
X83 2-way connector
X87 Left general line interface - 13-way
connector
X88 Right side general line interface - 17-way
connector
X106 Engine control unit - 89-way connector
X107 Water in fuel - 3-way connector
X110 Air conditioning - 3-way connector
X111 Air conditioning - 9-way connector
X130 12-way connector
X132 6-way connector
X144 2-way connector
X201.P Pilot control - 1-way connector
X201.S Pilot control - 1-way connector
X202 Backhoe attachment travel solenoid valve -
2-way connector
X203 Backhoe attachment lock solenoid valve -
2-way connector
X204 Horn switch - 2-way connector
X206 Bucket level - 2-way connector
X207 Speed control solenoid valve (optional) - 2-
way connector
X208 Loader attachment - 2-way connector
X209 Rear hammer solenoid valve - 2-way
connector
X210 Transmissione disconnect - 2-way
connector
XC1 Fuse and relay control unit line interface -
general line - 11-way connector
XC2 Fuse and relay control unit line interface -
general line - 7-way connector
XC3 Fuse and relay control unit line interface -
general line - 21-way connector
XC4 Fuse and relay control unit line interface -
general line - 21-way connector
NAME DESCRIPTION
XC5 Fuse and relay control unit line interface -
general line - 17-way connector
XC6 Fuse and relay control unit line interface -
general line - 13-way connector
XST1 Side instrument cluster - 20-way connector
XST2 Front instrument cluster - 20-way connector
XX From pilot control cable
NAME DESCRIPTION
