CHC i80 User Manual

2. Getting started with i80
i80 GNSS Receiver User Guide  Page 11
In the field:
The external power cable is connecting with a vehicle battery, the output
port of the external power cable connects with the Power Port of the GPS to
PC Data Cable/USB Cable.
WARNING - Use caution when connecting external power cable's clip leads
to a vehicle battery. Do not allow any metal object to connect (short) the
battery's positive (+) terminal to either the negative (-) terminal or the metal
part of the vehicle battery. This could result in high current, arcing, and high
temperatures, exposing the user to possible injury.
2.4. INSERTING BATTERY AND SIM CARD
Push down the spring-loaded button on the battery cover to open the cover.
Make electrode sheets of battery turn toward the receiver, align the socket
of the battery and the lug of the battery compartment, and then insert the
battery into the battery compartment until it is locked by the battery bail.
To remove the battery, slide the battery bail to the left or right.
