5. Rover station setup and operation
i80 GNSS Receiver User Guide Page 48
Note – Before switch to other communication mode, please tap in
Communication Mode screen to break the connection to the network.
5.3.3. RECEIVING CORRECTIONS USING CELLULAR MODEM IN THE
CONTROLLER
1. Power on the receiver.
2. Insert a SIM card into SIM card slot of your controller, and then turn on
the controller to establish network connection (please refer to
corresponding user guide of the controller that you are using for
instruction).
3. Run LandStar 6 on the controller → create a new project or open an
existing project → establish the connection with receiver via Bluetooth
or Wi-Fi (see 2.7. Connecting to a controller for the operations).
4. After successful connection, tap Rover Config in the Device screen.
5. In Rover Config screen, configure the related parameters from the
dropdown list or enter the value with the soft keyboard: Data Format,
Elevation Mask, PDOP Limit, Safe Mode and Iono Condition.
Note – Select the Data Format the same as that of base receiver.
6. Configure the antenna parameters as follows:
Type field: tap next to Type field to select CHCi80 as antenna type.
Measure To field: select Bottom from the dropdown list.
Height field: enter the height (in meters) of the range pole you are
using.
7. If required, tick Warning when base changed option → tap in the
lower right corner to save the settings and go back to Device screen.
