2. Getting started with i80
i80 GNSS Receiver User Guide Page 25
2.8.2. FOR FIRMWARE UPGRADE
1. Copy the firmware file (xxx.bin file) to the root directory of external
storage device such as USB drive, portable hard drive.
2. Connect the external storage device with receiver through USB port
using the OTG cable.
3. Restart the receiver and then the LCD screen will prompt you whether
to upgrade the firmware.
4. Press Fn button to upgrade the firmware.
5. When the upgrading is completed, the receiver will be restarted and the
LCD screen will prompt you whether to upgrade the firmware again.
6. Press Enter button to quit the upgrading and then remove the OTG
cable.
Note – You can also use Wi-Fi to upgrade the firmware for your receiver
using the web browser (see 7.11.3. Firmware update submenu for
instruction).
2.9. DOWNLOADING LOGGED DATA
Data logging involves the collection of GNSS measurement data over a
period of time at a static point or points, and subsequent postprocessing of
the information to accurately compute baseline information. Data logging
using receivers requires access to suitable GNSS postprocessing software
such as the CHC Geomatics Office (CGO) Software.
The following figure shows how to connect to the computer for downloading
logged data:
