4. Base station setup and operation
i80 GNSS Receiver User Guide  Page 36
4.2.2. CONFIGURING THE BASE STATION
4.2.2.1. Configuring via Hcconfig software
1. Power on the receiver.
2. Turn on the controller, run Hcconfig and establish the connection with
receiver via Bluetooth or Wi-Fi (see 2.7. Connecting to a controller for
the operations).
3. After successful connection, tap RTK in the main menu.
4. In RTK screen, select Mode from the dropdown list.
When select Auto Base for Mode field:
5. Configure the related parameters: Format, Baud, Elevation and PDOP.
6. Tick Radio option for Enable IO.
7. Tap Set button to save the settings, and then tap Back button to go back
to main menu.
8. Tap GPRS And Internal UHF in the main menu, select Internal UHF for
Work Mode.
9. Configure the internal radio parameters according to your need:
Frequency and Power.
10. Tick Auto Power and Power on to turn on the internal UHF modem.
11. Tap Set button to save the settings → tap Back button to go back to
main menu →tap Exit → select Exit Software Only option to exit
Hcconfig.
When select Manual Base for Mode field:
Slant height
