4. Base station setup and operation

i80 GNSS Receiver User Guide  Page 40

6. Tick Port option for Enable IO.

7. Tap Set button to save the settings → tap Back button to go back to

main menu →tap Exit → select Exit Software Only option to exit

Hcconfig.

8. After the receiver is successfully transmitting correction data (with the

green LED flashing once per second), power on the external radio, and

then configure the external radio from its panel.

When select Manual Base for Mode field:

5. Configure the related parameters: Format, Baud, Elevation and PDOP.

6. Tap Here button to obtain the current position or manually enter the

coordination of the known point in B, L and H.

7. Tick Port option for Enable IO.

8. Tap Set button to save the settings → tap Back button to go back to

main menu →tap Exit → select Exit Software Only option to exit

Hcconfig.

9. After the receiver is successfully transmitting correction data (with the

green LED flashing once per second), power on the external radio, and

then configure the external radio from its panel.

4.3.2.2. Configuring via LandStar 6 software

1. Power on the receiver.

2. Turn on the controller → run LandStar 6 → create a new project or open

an existing project → establish the connection with receiver via

Bluetooth or Wi-Fi (see 2.7. Connecting to a controller for the

operations).

3. After successful connection, tap Communication Mode in the Device

screen.

4. In Communication Mode screen, select External Radio for Mode → tap

in the lower right corner to back to Device screen.

5. Tap Base Config → select Start Base Station tab.

6. Configure the GNSS antenna related parameters as follows:

Type field: tap next to Type field to select CHCi80 as antenna type.

Measure To field: select Bottom from the dropdown list.

Height field: enter the vertical height (in meters) you calculated from

the known (control) point to the bottom of receiver for

Height field.

7. Configure the coordinates of base station.

There are three methods available to configure the base station
