Chroma 63600-2 User Manual

General Information
1-13
Range
0~16V
0~80V
0~150V
Output
0~10V
Accuracy
0.5%F.S.
Current Monitor
Bandwidth
20 kHz
Range
0~1A
0~6A
0~60A
Output
0~10V
Accuracy
0.5%F.S.
Protection
Over Power
Yes
Over Current
Yes
Over Voltage Alarm *
8
Yes
Over Temperature
Yes
Reverse
Yes
Interface
USB
Standard
Remote controller
Optional
Ethernet
Optional
GPIB
Optional
System Bus
Master/Slave & Remote Controller
Others
Dout
No. of bits
2 bits per mainframe
Level - H
1.8V/3.3V/5V switchable
Level - L
<0.6V@Isink=10mA
Drive
Pull_up resistor = 4.7kΩ
Din (TTL Compatible)
No. of bits
2 bits per mainframe
External Trig. for Digitizing(TTL Compatible, Rising edge)
No. of bits
1 bit per mainframe
External Trig. for Auto Sequences(TTL Compatible, Rising edge)
No. of bits
1 bit per mainframe
Load ON - O/P
Level
TTL Compatible, Level, Active High
Short ON - O/P
No. of channels
2 channels per 63600-1 mainframe
4 channels per 63600-2 mainframe
10 channels per 63600-5 mainframe
6 channels per 63601-5 mainframe
Level
TTL Compatible, Level, Active High
General
Short circuit
Current *
6
Set to 100% of rated current
Input Resistance(Load Off), Typical *
12
700kΩ
Dimensions (HxWxD)
142x86x514mm / 5.6x3.4x20.2 inch
Weight
4.5kg / 8.8 lbs
Operating Temperature
0~40°C
Storage Temperature
-20~80°C
Power
Supply from mainframe
EMC & Safety
CE
Model
63600-1
63600-2
Number of slots
1 slot
2 slots
Operating
temperature
0~40°C 0~40°C
Input Rating
1
φ 100~115VAC ±10%V
LN
1φ 200~230VAC ±10%V
LN
Switchable / 47~63Hz
1
φ 100~115VAC ±10%V
LN
1φ 200~230VAC ±10%V
LN
Switchable / 47~63Hz
Mainframe
dimension
(HxWxD)
177x90x554mm /
7.0x3.5x21.8 inch
177x210x554mm /
7.0x8.27x21.8 inch
Weight
7.5kg / 16.53lbs
11.5kg / 25.35lbs
Model*
14
63600-5
63601-5
Number of slots
5 slots
5 slots
Operating
temperature
0~40°C 0~40°C

Chroma 63600-2 Specifications

General

Brand	Chroma
Model	63600-2
Category	Power Supply
Language	English
