Input Rating
1
φ 100~115VAC ±10%V
LN
1φ 200~230VAC ±10%V
LN
Auto Range / 47~63Hz
1
φ 100~240VAC ±10%V
LN
Auto Range / 47~63Hz
Mainframe
dimension
(HxWxD)
177x447x554mm /
7.0x17.6x21.8 inch (Full Rack)
177x447x554mm /
7.0x17.6x21.8 inch (Full Rack)
Weight
15.6kg / 34.39lbs
13.6kg / 29.98lbs
NOTE*1: The maximum current loading below the minimum operating voltage (0.5V) will follow a derating curve.
NOTE*2: The 400W power rating of the 63640-80-80 specified at an ambient
temperature of 35℃, please refer to the power rating curve on the right.
NOTE*3: Does not apply to setting current < 0.25% full scale current in high range.
Does not apply to setting current < 0.05% full scale current in low and middle range.
NOTE*4: Power F.S.=Vrange F.S. x Irange F.S.
NOTE*5: The DC level measurements are made over a period of 20ms, and does not
measure any transient signals in the DC measurements.
NOTE*6: Its limits are the maximum power and maximum current of the current range.
NOTE*7: The 63600 is guaranteed to meet specified performance at temperature range
of 25±5℃.
NOTE*8: If the operating voltage exceeds the rated voltage for 1.1 times, it would cause
permanent damage to the device.
NOTE*9: Please refer to user's manual for detail specifications, and S (siemens) is the SI unit of conductance, equal to one
reciprocal ohm.
NOTE*10: Ext. Wave Mode: CC minimum driving current is 0.2mA.
NOTE*11: It is the minimum voltage of load measured by Oscilloscope.
NOTE*12: It is the current setting and measurement spec. of each mode not including the leakage current caused by Input
Resistance. If leakage current exceeds 0.05%FS, the influence of Input Resistance needs to be taken into consideration.
NOTE*13: Besides the accuracy 0.2%F.S for voltage measurement, 300µs delay time needs to be added.
NOTE*14: The 63601-5 only supports 6 Channels (CH1, CH3, CH5, CH7, CH9 and CH10.)
NOTE*15: When loading 60A continuously within 1 minute, the minimum working voltage can drop to 1.6V.
NOTE*16: The test conditions are 0.5µH under for line sense, CCDH loading 0~60A, SR: 0.4A/μs and Overshoot <5%. If the SR
is 6A/µs, the Overshoot should be smaller than 5% and the minimum working voltage must be above 2.5V.
NOTE*17: CCM: When the loading current is <10mA: 0.04%+0.12% F.S
Table 1
63610-80-20
63630-80-60
63640-80-80
63630-600-15
63640-150-60
CRH
(unit: S)
0.32879m / V
sense
0.98638m / V
sense
1.32206m / V
sense
0.2661m / V
sense
1m/V
sense
CRM
(unit: S)
CRL
(unit: S)
Table 2
63610-80-20
63630-80-60
63640-80-80
63630-600-15
63640-150-60
CPH
(unit: W)
0.32879m
x
V
sense
0.98638m
x
V
sense
1.32206m
x
V
sense
0.2661m
x
V
sense
1m
x
V
sense
CPM
(unit: W)
0.03285m
x
V
sense
0.09861m
x
V
sense
0.131517m
x
V
sense
0.026m
x
V
sense
0.1m
x
V
sense
CPL
(unit: W)
0.00326m
x
V
sense
0.00984m
x
V
sense
0.01310m
x
V
sense
0.00277m
x
V
sense
0.02m
x
V
sense
