CipherLab 9700 Reference Manual

93
Chapte
r
4 Radios
Note: Wi-Fi power settings under Wireless Manager will be kept through suspension and
warm boot/cold boot. After the mobile computer resumes from suspension or
restarts, Wi-Fi power status will be maintained and the mobile computer will attempt
to reconnect the previous connection.
SYSTEM TRAY ICON
The taskbar features a system tray icon to show Wi-Fi status.
The icons available for Wi-Fi connection are as follows:
Icon
Description
Indicates no Wi-Fi connection is established.
Indicates poor Wi-Fi signal (RSSI value is -90 dBm or weaker).
Indicates relatively low Wi-Fi signal (RSSI value is stronger than -90 dBm but does not
exceed -70 dBm).
Indicates good Wi-Fi signal (RSSI value is stronger than -70 dBm but does not exceed
-50 dBm).
Indicates high Wi-Fi signal (RSSI value is stronger than -50 dBm).

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
