CipherLab 9700 Reference Manual

201
PLATFORM, PROCESSOR & MEMORY
Operating System & CPU
OS Version Microsoft Windows Embedded Compact 6.0
CPU TI OMAP3730 1GHz Processor
Memory
RAM 512MB DDR SDRAM
Flash 4GB Flash ROM
Expansion Slot One expansion slot, supports MicroSDHC up to 32GB
COMMUNICATIONS & DATA CAPTURE
Communications
USB Host/Client USB 2.0
WPAN Built-in module for Bluetooth version 2.1 + EDR Class II connectivity
WLAN Built-in Cisco
©
CCX v4 certified module for 802.11 a/b/g/n networking
Data & Image Capture
Barcode Reader Ordering options include
STANDARD READER UNIT
 Laser (Symbol SE955)
 2D imager (Symbol SE4500)
LARGE READER UNIT
 2D imager with decoder board (Symbol
SE4500+PL4507)
 Extra long range laser (Symbol SE1524)
 Extra long range 2D imager (Intermec
EX25)
SPECIFICATIONS

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
