CipherLab 9700 Reference Manual

55
Although highly converged, the mobile computer is also a dedicated barcode reader. The
mobile computer is shipped with either a (laser) 1D reader or 2D imager. A number of
symbologies are supported and data about them can be decoded and collected.
After data has been collected, the mobile computer can output it locally to applications
installed on the mobile computer or to the host computer so data storage, advanced data
analysis and more special services can be performed.
This chapter describes how to collect data with reader modules.
2. IN THIS CHAPTER
2.1 Configure Reader....................................................... 56
2.2 Read Printed Barcodes................................................ 73
Chapter 2
DATA CAPTURE

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
