CipherLab 9700 Reference Manual

78
9700 Mobile Computer (CE) Reference Manual
A specific wireless connection has been established successfully.
Double-tap the icon to open a dialog to check IP information. Included connections
are:
 Bluetooth PAN
 802.11a/b/g/n
Indicates the Wi-Fi module is enabled. The more the green bars, the stronger the
signal.
3.1.2. START MENU
Tap the Start button on the taskbar to open the Start Menu.
Options
Description
Programs Accesses programs stored in the directory My Device\Windows\Programs.
Favorites Accesses favorite links to webpages that are stored under the directory
My Device\Windows\Favorites.
Documents Accesses recently opened documents stored under the directory
My Device\Windows\Recent.
Settings Provides access to the following:
 Control Panel
 Network and Dial-up Connections
 Taskbar and Start Menu
Run
Opens a program, folder or document as specified.
Start menu

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
