The tables below list the symbology settings for the 1D extra long range laser scan engine
(SE1524).
SYMBOLOGY SETTINGS
Symbology Description Default
CODABAR
CodaBar
Codabar Checkbox to enable Codabar decoding. Enable
Length option Sets the length of the Codabar symbols to decode.
One Fixed length (Length 1)
Two Fixed lengths (Length 1>Length 2)
Max / Min Length (range: 0-55; Length 1<Length 2)
Any Length
Max / Min
Length
(4-55)
CLSI When applied, the CLSI editing strips the start/stop
characters and inserts a space after the first, fifth, and tenth
characters of a 14-character Codabar barcode.
The 14-character barcode length does not include
start/stop characters.
Disable
NOTIS Sets whether to include start/stop characters in the
transmitted data.
NOTIS Editing is to strip the start/stop characters, i.e. to
disable "Transmit Start/Stop Characters".
Disable
CODE 39
Code 39
Code 39 Checkbox to enable Code 39 decoding. Enable
Trioptic Code 39 Selects whether to decode Trioptic Code 39.
Trioptic Code 39 is a variant of Code 39 used in the
marking of computer tape cartridges. It always contains
six characters.
Disable
Convert to Code 32 Selects whether to convert decoded data to Italian
Pharmacode.
Disable
Code 32 Prefix Prefix character “A” to Code 32 barcodes.
Convert to Code 32” must be enabled for this to
function properly.
Disable
Verify Check Digit Selects whether to verify the Modulo 43 check digit. If the
check digit is incorrect, the barcode will not be accepted.
Disable
Transmit Check Digit Decide whether to include the check digit in the data to
transmit.
“Verify Check Digit” must be enabled.
Disable
Appendix III
LASER (SE1524)
To Next Page
