6.3. CONNECTION SETTINGS
To access connection settings:
 Tap Start | Settings | Control Panel | Network and Dial-up Connections.
OR
 Tap Start | Settings | Network and Dial-up Connections.
Icon
Description
MAKE NEW CONNECTION
Tap to create a new connection which is not listed.
USB SERIAL
Sets serial profile for USB connection to a PC via ActiveSync. Settings will be
reflected under Start | Settings | Control Panel | PC Connection
. When
the mobile computer is connected to a PC, the connection is enabled
automatically.
 When connected, an icon will appear on the taskbar.
 When disconnected, the icon will disappear.
Note: Any changes to the Properties of this item will affect ActiveSync
connection.
USB CABLE
Sets USB networking with the PC through RNDIS. This appears automatically
when the mobile computer is connected to a PC via the Snap-on Cable or Cradle,
and the icon disappears when the mobile computer is disconnected from the PC.
SDCSD40N1
Refers to the 802.11 a/b/g/n module for connection via wireless local area
network (WLAN). To enable this function, turn on Wi-Fi power in Start | Settings
| Control Panel | Wireless Manager
.
 An icon is located on the taskbar.
 When connected to WLAN, the icon will change to .
 When disconnected, the icon will return to .
BTPAN1
Refers to connection via wireless personal area network (WPAN). This function is
not available until Bluetooth power is turned on in Start | Settings | Control
Panel | Wireless Manager
.
 When Bluetooth power is turned on, an icon will appear on the taskbar.
 When connected to a Bluetooth device, the icon will change to .
 When disconnected to a Bluetooth device, the icon will return to .
 When Bluetooth power is turned off, the icon will disappear.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
