CipherLab 9700 Reference Manual

118
9700 Mobile Computer (CE) Reference Manual
4.2. USE BLUETOOTH
The mobile computer is Bluetooth-enabled to synchronize data with other devices such as
PCs, car hands-free kits, headsets, printers, PDAs, and cell phones.
Class II Bluetooth devices enable wireless connections over a short distance of around 10
meters. It is specified in IEEE 802.15.1 as a “wireless personal area network” (WPAN).
To connect a Bluetooth device for the first time, the mobile computer needs to “pair” with it.
Such “pairing” involves authentication between two devices to justify their accesses to each
other. After this initial pairing, the two devices can connect to each other without the need
of a second pairing procedure.
4.2.1. BLUETOOTH PROFILES SUPPORTED
Bluetooth Profiles Supported
Serial Port Profile (SPP) supports Server/Client
Object Push Profile (OPP) supports Server/Client
File Transfer Profile (FTP) supports Server/Client
Personal Area Networking Profile (PAN)
Human Interface Device Profile (HID) supports keyboard and mouse without cursor
Headset Profile (HSP)
Hands-Free Profile (HFP)
4.2.2. CHANGE BLUTOOTH NAME
By default, the mobile computer uses the device name for its Bluetooth name. Change the
device name to make it more recognizable.
To change the mobile computer’s device name:
1) Tap Start | Settings | Control Panel | System
.
System Properties page opens showing General tabbed page.
2) Tap Device Name tab.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
